CNC milling
worko
w
109
•
For materials larger than workspace of ZMorph VX ther
e are M4 threaded holes for
mounting your material with M4 screws.
T
ypes of workholding solutions
Y
our workholding solutio
n should be adapted to material and its dimensions t
o ensure
best results.
T
-slots for M4 screw / square nut based xturing
M4 threaded holes for out-of-workspace xturing
