Maint
enance
38
Left and right cover
.
Side covers
T
o remove side co
vers:
Find the two hooks
blocking the covers.
Release the cover r
ear
corner from the hooks
by gently squeezing the
cover
.
Pull out the cover r
ear
corner from the machine
frame.
Pull out the cover upper
corner from the machine
frame.
NO
TE:
T
o
mount
a
cover
,
rstly
slide
in
the
upper
side.
Then
adjust
the
lower
side
and
place it in the hooks.
Side covers ar
e NOT
identical.
The right cover contains a place for the screen.
