Step Action
1
Remove the Manifold Assembly from the Top
Panel Connector and the Compressor Pump.
Remove 4 screws at SPM Oxygen Inlet Manifold
to separate it from the SPM Mix Manifold.
Remove 4 screws at SPM Mix Manifold to
separate it from the Compressor-SPM Connector.
2
On the SPM Mix Manifold, insert the O-Ring ½"
OD X 3/8" ID (P/N 340-0023-00).
NOTE: Ensure that it sits fully in the counter bore
of the bottom.
To Next Page
