ZOLL EMV+ - Page 147

Service Kit Installation Procedures
4–92 www.zoll.com 906-0731-04-01 Rev. C
10 Insert the Transducer, Screen, 400 Mesh with the
smaller diameter into the SPM Oxygen Inlet
Manifold.
NOTE: Ensure that it sits properly in the counter
bore.
11 Insert the O-Ring ½" ID X 5/8" OD X .0629 (P/N
340-0059-00) into the SPM Oxygen Inlet
Manifold.
NOTE: Ensure that it sits properly in the counter
bore.
Step Action
