Chapter 35 File Manager
ZyWALL (ZLD) CLI Reference Guide
283
Figure 35 atuk Command for Restoring the Recovery Image
4 Enter Y and wait for the “Starting XMODEM upload” message before activating
XMODEM upload on your terminal.
Figure 36 Starting Xmodem Upload
5 This is an example Xmodem configuration upload using HyperTerminal. Click
Transfer, then Send File to display the following screen.
Figure 37 Example Xmodem Upload
6 Wait for about three and a half minutes for the Xmodem upload to finish.
Figure 38 Recovery Image Upload Complete
7 Enter atgo. The ZyWALL starts up. If “Connect a computer to port 1 and FTP to
192.168.1.1 to upload the new file” displays on the screen, the firmware file is damaged
and you need to use the procedure in Section 35.10 on page 284 to recover the firmware.
Type the firmware file's
location, or click Browse to
search for it.
Choose the 1K Xmodem
protocol.
Then click Send.
