Connecting the NIC to the Network 35
3 Connect the other end of the network cable to a
10BASE-FL Ethernet network hub or switch.
Insert the cable that is connected to the transmit (10)
connector on the NIC into the receive (RX) connector on
the network hub or switch.
Insert the cable that is connected to the receive (RX)
connector on the NIC into the transmit (TX) connector
on the network hub or switch.
The next step is to install the network driver.
Go to Chapter 3, “Installing NIC Software in Windows,” or
Chapter 4, “Installing the NetWare Client and Server Drivers.”
