60 CHAPTER 5: CONFIGURING THE NIC
4 If your PC has more than one NIC installed, open the
Network Interface Card (NIC) list box and select the
NIC to be configured.
5 Click the Configuration tab.
The Configuration screen appears.
6 Under Network Parameter, select the setting to
be changed.
For a description of each setting, click the question mark (?)
in the upper right corner of the screen, move it over a
setting, and click once.
7 Open the Set Value list box and select a new value
from the list of available options.
Repeat the process to change any other configuration
setting.
To undo changes and return the settings to their previous
values, click Undo Changes.
To return the settings to the factory default settings, click
Set Factory Defaults.
8 Click OK to save the changes and exit the program.
Configuring the Managed PC Boot Agent (MBA)
This section explains how to configure the 3C905C-TX-M
and 3C905B-TX-M NICs’ Managed PC Boot Agent (MBA)
boot ROM to boot from the network.
Click Help to obtain general information about the
function of a screen. To obtain specific information about
any topic on a screen, click the question mark (?) in the
upper right corner of the screen, move it over a topic, and
click once.
For detailed information on using, configuring,
and troubleshooting the MBA boot ROM, see the
Managed PC Boot Agent User Guide, located with
the MBA software on the EtherCD.
