28 CHAPTER 2: INSTALLING AND CONNECTING THE NIC
Connecting the Remote Wake-Up Cable
This section describes how to connect the Remote Wake-Up
cable from the NIC to the PC motherboard.
Connecting the Remote Wake-Up cable is optional.
Connect this cable only if your NIC supports
Remote Wake-Up and you want to use this feature.
The following NICs support Remote Wake-Up:
■ 3C905C-TX-M
■ 3C905B-TX
■ 3C905B-TX-M
■ 3C905B-COMBO
■ 3C905B-FX
■ 3C900B-FL
To connect the Remote Wake-Up cable:
1 Make sure that the NIC is properly installed in a PCI slot.
2 Insert the Remote Wake-Up cable into the
RWU connector on the NIC.
Twist the cable twice before attaching the cable to the PC.
3 Attach the other end of the cable to the connector on
the PC motherboard.
Refer to your PC documentation if you need help locating
the connector.
If you have a 3C905C-TX-M NIC and your PC is compliant
with PCI 2.2, Remote Wake-Up is automatically enabled
through the PCI bus. You do not need to connect the
Remote Wake-Up cable.
WARNING: Make sure that the PC power cord is
unplugged. Only properly trained and authorized
personnel should perform service. Contact your PC
manufacturer for information about safe service
techniques.
