333D SYSTEMS, INC.
5
SYSTEM USE
POWERING UP THE PRINTER
1. Make sure printer is plugged into the facility power.
2. Make sure that the 32A circuit-breaker is engaged upstream of the machine.
3. Turn on the main switch on the connection panel of the control/supply cabinet (1).
4. Switch on the UPS (see section "E. Control/supply cabinet" on page 28).
5. Make sure that all doors are closed and emergency stop is not pushed.
6. Switch the locking key to position “1”, on the external control panel (2).
7. Open the compressed air valve (3) and gas valve (4).
8. Start the machine by pressing the start push button, on the external control panel (5).
9. The PX Control application will automatically start and be displayed on the screen control panel.
To launch the PX Control application manually, double-click on the icon “PX_Control” from the desktop.
2
1
3
4
5
PX Control 2.X.X.2
To Next Page
Loading...
Need help?
General
