EVERY 6 MONTHS MAINTENANCE
Clamping lter inspection/replacement
The clamping lter must be inspected once a month, and replaced every 6 months. The clamping lter is located on the left
side.
Part required:
• Filter element : 1001884R00.
• Damp cotton cloth.
Caution: wear PPE (disposable rubber gloves, anti-static coverall, FFP3 respiratory protection, anti-static
safety shoes).
Procedure:
1. Deactivate the clamping system.
2. Open the left side door of the control cabinet (1) and inspect the clamping lter (2).
3. During inspecting:
• If metal powder is covering large surface of the lter element or is
found at the bottom of the lter guard, then proceed to the next
step.
• If the inspection does not reveal any presence of powder, then t
back the cover plate removed previously.
The following steps must be performed if the lter element contains excessive metal powder (see step 2)
or according to the recommended maintenance interval.
4. Remove the lter guard from the lter cap by unscrewing it.
Caution : Wear disposable rubber gloves and leather
gloves during the lter guard removal.
5. Remove the lter element. Dispose of it in accordance with all local/regional/national, state and federal regulations.
WARNING : FLAMMABLE POWDERS.
PLACE THE USED FILTER ELEMENT IN A CLOSED METALLIC CONTAINER IN A ROOM WITH FIRE DETECTION.
6. Clean the lter guard with the use of a damp cotton cloth.
7. Install the new lter element.
8. Install the lter guard.
9. Fit back the cover plate previously removed.
