353D SYSTEMS, INC.
Preparation menu
By clicking on the Preparation Menu button, the “PX Control : Preparation assistant” window appears.
Click "Validate" to conrm, or "Quit" to cancel.
NOTE: this window will appear only if the machine has nished the
previous preparation. Otherwise, the application will display the
Preparation Assistant window at the current step.
The Preparation Menu allows user to prepare the printer to print a job, and to unload the printed part.
This menu is composed by 8 successive steps. Each step shows manual and automatic actions to be performed, and
consists of :
1
List of the preparation steps (green: completed, blue: in progress, grey: not performed)
2
Actions executed during the automatic cycle
3
Button to launch the current cycle
4
List of actions of the current step to be performed by the operator
5
Available commands of the current step
6
Button to navigate to the next step
1
2
4
6
5
3
