HARDWARE
Display the status of components, alarms and switch (green light = OK, orange light = caution, red light = fault/warning):
• Supply:
• status of various power supplies of the machine (compressed air supply, gas supply, and power supply),
• the gas type (corresponds to the value set in the Conguration menu (see section "Conguration" on page 47)).
• Oxygen sensor:
• status of the oxygen sensor,
• status of the oxygen alarm: orange light if oxygen level measured by the sensor is higher than the required level.
• position of the safety override switch (see section "E. Control/supply cabinet" on page 28):
- White light = switch in "standard mode" position (system in normal operating mode),
- Yellow light = switch in "service mode" position.
• Safety:
• status of the safety of the machine and interlocks states (open, locked) that can block a movement or a
manufacturing start,
• Laser:
• type of laser,
• status: Ready, Emission, Aiming (yellow light = aiming activated; see section "Manufacturing menu" on page 43).
• Scanner head: state of the thermo-couples, and the temperature values,
• Axes: indicates the state of the 2 drivers, of the 4 motors, and the corresponding error code.
Warning tooltip (encircled number)
Displayed only if one of the followings occures. It indicates the number of:
• orange lights activated of the lter timers: the corresponding number is displayed with orange background.
• red lights activated of the lter timers or any sensor fault: the corresponding total number is displayed with red back-
ground.
If both colors occur, the red one is only displayed.
If none of them occur, the tooltip is not displayed.
