573D SYSTEMS, INC.
• Airlock door
To access to the airlock door, the front doors must be opened.
The mechanism to open/close the door is a quarter-turn lock system.
• Airlock positions
The airlock (or sas) is controlled from the screen control panel, as per the following:
OPEN = airlock facing the operator side,
CLOSE = airlock facing the chamber side.
• Tools required
• A natural ber brush for the cleaning process.
• A tamping plate to compact the powder from the feeding piston. A standard sintering plate can be used as a
tamping plate by xing a M5x4mm screw secured with a nut (the reverse of a standard sintering plate has a tapped
hole in its center).
M5 screw
Nut
Standard sintering plate
1
2
Airlock door closed and
locked.
Airlock door unlocked and
opened.
