Pannoramic SCAN II 2.2.0 User’s Guide 1 Product Description
1 Product Description
1.1 Product Overview
1.1.1 Intended Use
The Pannoramic® SCAN II is designed to use transmitted light and reflected light fluorescence to
digitize biological samples and specimens (histological sections, typically). The target users of the
product can work for example, in education, research, industrial, or medical sectors.
Warning!
After each scanning make sure to inspect the digital slide for over-exposed
areas. If the slide is scanned based on improperly set parameters, it can
highly affect the diagnostic result because of information loss.
Warning!
Any modification to a hardware or software component of the PC will
highly affect the functionality of the scanner program.
1.1.2 Features and Benefits
The Pannoramic® SCAN II offers world class brightfield and fluorescent whole slide scanning on up to
9 channels. An outstanding 0.12 µm/pixel (in Brightfield) and 0.16 µm/pixel (in Fluorescent)
resolution is achieved with the 40×/NA 0.95 (equivalent to 80× magnification in BF and 62×
magnification in FL) Plan-Apochromat objective.
Key features of the Pannoramic® SCAN II Scanner are:
• A single monochrome camera is used for both Brightfield and Fluorescent scanning modes
• LED-based RGB illumination unit
• Up to 9 freely selectable physical color filters for fluorescence
• High-end fluorescent illumination device – Lumencor SPECTRA 6 Light Engine
• Multiband filter support
January 24, 2020 - Rev. 2 3DHISTECH Ltd. 14(156)
