Pannoramic SCAN II 2.2.0 User’s Guide 5.2.2 Microscope Control Panel
5.2.2 Microscope Control Panel
5.2.2.1 Preview window
Click to open the Preview panel that offers options for threshold setting and selection of the
area to be scanned.
Figure 44 – Pre-scan preview image
Threshold options
This section is located at right side of the preview window. Scanmap Source is designed to set which
type of scanmap is used on the preview image. This scanmap is displayed automatically in the Profile
Scanmap Source setting. Selectable scanmap types are the following:
• Use threshold
• Load previously saved scanmap from file
• Custom scan map
January 24, 2020 - Rev. 2 3DHISTECH Ltd. 85(156)
