Pannoramic SCAN II 2.2.0 User’s Guide 5.1.2 Microscope Control Panel
5.1.2 Microscope Control Panel
The Microscope Control panel includes the main control features of the microscope.
5.1.2.1 Preview Window
The Preview panel offers options for threshold setting and selection of the area to be scanned.
Figure 24 – Preview panel
Threshold options
This section is located at right side of the preview window. Scanmap Source is designed to set which
type of scanmap is used on the preview image. This scanmap is displayed automatically in the Profile
Scanmap Source setting. Selectable scanmap types are the following:
• Use threshold
• Load previously saved scanmap from file
• Custom scan map
January 24, 2020 - Rev. 2 3DHISTECH Ltd. 62(156)
