3DHISTECH Pannoramic SCAN II User Manual

Pannoramic SCAN II 2.2.0 User’s Guide 7 Technical Data
Light sources
Brightfield illumination PAX-601-3 Precision-Aligned Pulsed Xenon Light Source
Average service life 1 x 10
9
flashes
Fluorescent light source 1 (optional) SOLA SM II 365 (5 solid-state sources producing white light)
Wavelength range 350–680 nm
Average service life 20 000 hours
Fluorescent light source 2 (optional) SPECTRA (6 individually addressable solid-state light sources)
Average service life 20 000 hours
Preview camera
Preview camera VRmagic VRmC-8+ PRO
Sensor CMOS, rolling shutter
Sensor size ½”
Resolution 2056x1544
Pixel size 3.2 um x 3.2 um
Max. frame rate 13 Hz
Bit depth 8/10 bit
Scan cameras
Point Grey Grasshopper3 (GS3-U3-51S5M-C)
Global Shutter Type CMOS (Sony IMX250)
Pixel size 3.45µm × 3.45µm
Camera resolution 2448 (H) × 2048 (W) pixel
Frames rates 75 fps
Bit-depth 10-bit / 12-bit
Pixel resolution with 20x objective and 0.63x C-mount adapter 0.27 µm
Pixel resolution with 20x objective and 1x C-mount adapter 0.17 µm
Pixel resolution with 40x objective and 0.63x C-mount adapter 0.14µm
Pixel resolution with 40x objective and 1x C-mount adapter 0.09 µm
Connection type USB 3.0
2020/ January 24/ - Rev. 2
3DHISTECH Ltd. 148(156)
