168 Parameters
Save to set 1 Save user parameter set 1. 18
Save to set 2 Save user parameter set 2. 19
Save to set 3 Save user parameter set 3. 20
Save to set 4 Save user parameter set 4. 21
96.12 User set I/O mode
in1
When parameter 96.11 User set save/load is set to User set
I/O mode, selects the user parameter set together with
parameter 96.13 User set I/O mode in2 as follows:
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Not applicable.
Timed function 2 Not applicable.
Timed function 3 Not applicable.
Supervision 1 Bit 0 of 32.01 Supervision status (see page 114). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 114). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 114). 26
Other [bit] Source selection (see Terms and abbreviations on page 64). -
96.13 User set I/O mode
in2
See parameter 96.12 User set I/O mode in1. Not selected
No. Name/Value Description Def/FbEq16
Status of source
defined by par.
96.12
Status of source
defined by par.
96.13
User parameter
set selected
00Set 1
10Set 2
01Set 3
11Set 4
ACQ80 FW.book Page 168 Thursday, February 14, 2019 11:33 AM
