ABB ACQ80-04 User Manual

Parameters 91
AO has automatic scaling. Every time the source for the AO is changed, the scaling range is
changed accordingly. User given minimum and maximum values override the automatic values.
-32768.0…32767.0 Real signal value corresponding to minimum AO1 output
value.
1 = 1
13.18 AO1 source max Defines the real maximum value of the signal (selected by
parameter 13.12 AO1 source) that corresponds to the
maximum required AO1 output value (defined by parameter
13.20 AO1 out at AO1 src max). See parameter 13.17 AO1
source min.
50.0
-32768.0…32767.0 Real signal value corresponding to maximum AO1 output
value.
1 = 1
13.19 AO1 out at AO1 src
min
Defines the minimum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
0.000 mA
0.000…22.000 mA /
0.000…11.000 V
Minimum AO1 output value. 1000 = 1 mA
13.20 AO1 out at AO1 src
max
Defines the maximum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
20.000 mA
0.000…22.000 mA /
0.000…11.000 V
Maximum AO1 output value. 1000 = 1 mA
No. Name/Value Description Def/FbEq16
13.12 AO1 source,
13.22 AO2 source
13.17 AO1 source min,
13.27 AO2 source min
13.18 AO1 source max,
13.28 AO2 source max
0Zero N/A (Output is constant zero.)
1 Motor speed used 0 99.09 Motor nominal speed
3 Output frequency 0 99.08 Motor nominal
frequency
4 Motor current 0 30.17 Maximum current
5 Motor current % of motor
nominal
0% 100%
6 Motor torque 0 46.03 Torque scaling
7 DC voltage Min. value of 01.11 DC
voltage
Max. value of 01.11 DC
voltage
8 Output power 0 46.04 Power scaling
12 Speed ref used 0 99.09 Motor nominal speed
14 Freq ref used 0 99.08 Motor nominal
frequency
16 Process PID out Min. value of 40.01 Process
PID output actual
Max. value of 40.01 Process
PID output actual
20 Temp sensor 1 excitation N/A (Analog output is not scaled; it is determined by the
sensor’s triggering voltage.)
21 Temp sensor 2 excitation
26 Abs motor speed used 0 99.09 Motor nominal speed
27 Abs motor speed % 0 99.09 Motor nominal speed
28 Abs output frequency 0 99.08 Motor nominal
frequency
30 Abs motor torque 0 46.03 Torque scaling
31 Abs output power 0 46.04 Power scaling
32 Abs motor shaft power 0 46.04 Power scaling
37 AO1 data storage 13.91 AO1 data storage (page
93).
13.91 AO1 data storage
38 AO2 data storage 13.92 AO2 data storage (page
93).
13.92 AO2 data storage
Other Min. value of the selected Max. value of the selected
ACQ80 FW.book Page 91 Thursday, February 14, 2019 11:33 AM
