ABB ACS150 series

129
Fault tracing
CODE
ALARM
CAUSE
WHAT TO DO
A2017
OFF BUTTON
Drive stop command has been
given from control panel when
local control lock is active.
Disable the local control mode lock by
parameter 1606 LOCAL LOCK and retry.
A2018
1)
PID SLEEP
Sleep function has entered the
sleeping mode.
See parameter group 40 PROCESS PID
SET 1.
A2023
EMERGENCY STOP
Drive has received emergency
stop command and ramps to stop
according to ramp time defined by
parameter 2208 EMERG DEC
TIME.
Check that it is safe to continue operation.
Return emergency stop push button to
normal position.
A2026
INPUT PHASE LOSS
(programmable
fault function,
parameter 3016
SUPPLY PHASE)
Intermediate circuit DC voltage is
oscillating due to missing input
power line phase or blown fuse.
Alarm is generated when DC
voltage ripple exceeds 14% of
nominal DC voltage.
Check input power line fuses.
Check for input power supply imbalance.
Check fault function parameter setting.
1)
Even when the relay output is configured to indicate alarm conditions (for example, parameter 1401
RELAY OUTPUT 1 = 5 [ALARM] or 16 [FLT/ALARM]), this alarm is not indicated by a relay outpu t.
CODE
CAUSE
WHAT TO DO
A5011
Drive is controlled from another source.
Change drive control to the local control mode.
A5012
Direction of rotation is locked.
Enable change of direction. See parameter 1003
DIRECTION.
A5013
Panel control is disabled because start inhibit is active.
Start from the panel is not possible. Reset the
emergency stop command or remove the 3-wire stop
command before starting from the panel.
See section 3-wire macro on page 72 and parameters
1001 EXT1 COMMANDS, 1002 EXT2 COMMANDS
and 2109 EMERG STOP SEL.
A5014
Panel control is disabled because of drive fault.
Reset drive fault and retry.
A5015
Panel control is disabled because the local control mode
lock is active.
Deactivate the local control mode lock and retry. See
parameter 1606 LOCAL LOCK.
A5019
Writing non-zero parameter value is prohibited.
Only parameter reset is allowed.
A5022
Parameter is write protected.
Parameter value is read-only and cannot be changed.
A5023
Parameter change is not allowed, when drive is running.
Stop drive and change parameter value.
A5024
Drive is executing task.
Wait until task is completed.
A5026
Value is at or below minimum limit.
Contact your local ABB representative.
A5027
Value is at or above maximum limit.
Contact your local ABB representative.
A5028
Invalid value
Contact your local ABB representative.
A5029
Memory is not ready.
Retry.
A5030
Invalid request
Contact your local ABB representative.
A5031
Drive is not ready for operation, for example, due to low
DC voltage.
Check input power supply.
A5032
Parameter error
Contact your local ABB representative.
