66
Control panel
12
.
0
Hz
PAR
SET
FWD
Step
Action
Display
6.
changed the parameter value,
SET
starts flashing.
To save the displayed parameter value, press .
To cancel the new value and keep the original, press .
LOC
LOC
1203
PAR FWD
103
PAR
SET
FWD
104
PAR
SET
FWD
LOC
105
PAR
SET
FWD
0
.
0
Hz
PAR
SET
FWD
500
.
0
Hz
LOC
PAR
SET
FWD
Step
Action
Display
1.
they are displayed with group 34 PANEL DISPLAY parameters. See page
65 for detailed instructions on changing parameter values.
0105 TORQUE.
To change the default signals, select from group 01 OPERATING DATA up
to three signals to be browsed.
Signal 1: Change the value of parameter 3401 SIGNAL1 PARAM to the
index of the signal parameter in group 01 OPERATING DATA (= number of
the parameter without the leading zero), for example, 105 means
parameter 0105 TORQUE. Value 0 means that no signal is displayed.
Repeat for signals 2 (3408 SIGNAL2 PARAM) and 3 (3415 SIGNAL3
PARAM). For example, if 3401 SIGNAL1 PARAM = 0 and 3415 SIGNAL3
PARAM = 0, browsing is disabled and only the signal specified by 3408
SIGNAL2 PARAM appears on the display. If all three parameters are set to
0, that is no signals are selected for monitoring, the panel displays text
“n.A.”.
LOC
LOC
2.
Specify the decimal point location, or use the decimal point location and
unit of the source signal (setting 9 [DIRECT]). For details, see parameter
3404 OUTPUT1 DSP FORM.
Signal 1: parameter 3404 OUTPUT1 DSP FORM
Signal 2: parameter 3411 OUTPUT2 DSP FORM
Signal 3: parameter 3418 OUTPUT3 DSP FORM.
LOC
9
PAR SET FWD
3.
Select the units to be displayed for the signals. This has no effect if
parameter 3404/3411/3418 is set to 9 (DIRECT). For details, see
parameter 3405 OUTPUT1 UNIT.
Signal 1: parameter 3405 OUTPUT1 UNIT
Signal 2: parameter 3412 OUTPUT2 UNIT
Signal 3: parameter 3419 OUTPUT3 UNIT.
LOC
3
PAR SET FWD
4.
maximum display values. This has no effect if parameter 3404/3411/3418 is
set to 9 (DIRECT). For details, see parameters 3406 OUTPUT1 MIN and
3407 OUTPUT1 MAX.
Signal 1: parameters 3406 OUTPUT1 MIN and 3407 OUTPUT1 MAX
Signal 2: parameters 3413 OUTPUT2 MIN and 3414 OUTPUT2 MAX
Signal 3: parameters 3420 OUTPUT3 MIN and 3421 OUTPUT3 MAX.
LOC
Use keys and to select the parameter value. When you have
How to select the monitored signals
You can select which signals are monitored in the Output mode and how
By default, the display shows: 0103 OUTPUT FREQ, 0104 CURRENT and
Select the scalings for the signals by specifying the minimum and
