What this chapter contains
The chapter describes the actual signals and parameters. It also contains a table of
the default values for the different macros.
Terms and abbreviations
Signal measured or calculated by the drive. Can be monitored by the user.
No user setting possible. Groups 01...04 contain actual signals.
A user-adjustable operation instruction of the drive. Groups 10...99 contain
parameters.
Refers to types 01E- and 03E- with European parametrization
Refers to types 01U- and 03U- with US parametrization
Default parameter values with different macros
When application macro is changed (9902 APPLIC MACRO), the software updates
the parameter values to their default values. The following table includes the
parameter default values for different macros. For other parameters, the default
values are the same for all macros (see section Actual signals on page 84).
