Control panel
Changed parameters mode
In the Changed parameters mode, you can:
• view a list of all parameters that have been changed from the macro default
values
• change these parameters
• start, stop, change direction, switch between local and remote control and set the
frequency reference.
How to view and edit changed parameters
Step
Action
Display
1.
Go to the Main menu by pressing if you are in the Output mode,
otherwise by pressing repeatedly until you see MENU at the bottom.
LOC
rEF
MENU FWD
2.
If the panel is not in the Changed parameters mode (“PArCh” not visible),
press key or until you see “PArCh” and then press . The
display shows the number of the first changed parameter and PAR is
flashing.
LOC
PArCh
MENU FWD
LOC
1103
PAR FWD
3.
Use keys and to find the desired changed parameter on the
list.
LOC
1003
PAR FWD
4.
Press and hold for about two seconds until the display shows the
value of the parameter with SET underneath indicating that changing of the
value is now possible.
Note: When SET is visible, pressing keys and
simultaneously changes the displayed value to the default value of the
parameter.
LOC
1
PAR SET FWD
5.
Use keys and to select the parameter value. When you have
changed the parameter value,
SET
starts flashing.
• To save the displayed parameter value, press .
• To cancel the new value and keep the original, press .
LOC
2
PAR SET FWD
LOC
1003
PAR FWD
