ABB ACS150 series User Manual

List of related manuals
Drive manuals Code (English)
ACS310 User’s Manual 1), 2) 3AFE68576032
Option manuals and guides
MUL1-R1 Installation instructions for ACS150,
ACS310, ACS320, ACS350 and ACS355
1), 2) 3AFE68642868
MFDT-01 FlashDrop user's manual 1), 2) 3AFE68591074
Maintenance manuals
Guide for capacitor reforming in ACS50, ACS55,
ACS150, ACS310, ACS350, ACS355, ACS550,
ACH550 and R1-R4 OINT-/SINT-boards
2) 3AFE68735190
1)
Delivered as a printed copy with the drive or optional equipment.
2)
Available in the Internet.
All manuals are available in PDF format on the Internet. See section Further information on the inside of the back cover.

ABB ACS150 series Specifications

General

Power Range	0.37 to 4 kW
Frequency Range	0 to 500 Hz
Protection Class	IP20
Overload Capacity	150% for 60 seconds
Braking Chopper	Built-in
Control Method	Scalar control
Supply Voltage	200-240 V (1-phase), 200-480 V (3-phase)
EMC Filter	Built-in
Input Voltage	200-240 V (1-phase), 200-480 V (3-phase)
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit
Communication Options	Modbus RTU
Voltage Range	200 to 240 V (1-phase), 380 to 480 V (3-phase)
