Mechanical installation
3. Position the drive onto the screws on the wall.
4. Tighten the screws in the wall securely.
3
4
On DIN rail
1. Click the drive to the rail. To detach the drive, press the release lever on top of the
drive as shown in Figure 1b.
1
1b
