Actual signals and parameters
Parameters in the Short parameter mode
The following table describes the parameters that are visible in the Short parameter
mode. See section Parameter modes on page 65 for how to select the parameter
mode. All parameters are presented in detail in section Parameters in the Long
parameter mode, starting on page 86.
Parameters in the Short parameter mode
No.
Name/Value
Description
Def
99 START-UP DATA
Application macro. Definition of motor set-up data.
9902 APPLIC MACRO
Selects the application macro or activates FlashDrop parameter values. See
chapter Application macros on page 69.
1 = ABB
STANDARD
1 = ABB STANDARD
Standard macro for constant speed applications
2 = 3-WIRE
3-wire macro for constant speed applications
3 = ALTERNATE
Alternate macro for start forward and start reverse applications
4 = MOTOR POT
Motor potentiometer macro for digital signal speed control applications
5 = HAND/AUTO
Hand/Auto macro to be used when two control devices are connected to the
drive:
- Device 1 communicates through the interface defined by external control
location EXT1.
- Device 2 communicates through the interface defined by external control
location EXT2.
EXT1 or EXT2 is active at a time. Switching between EXT1/2 through digital
input.
6 = PID CONTROL
PID control. For applications in which the drive controls a process value. For
example, pressure control by the drive running the pressure boost pump.
Measured pressure and the pressure reference are connected to the drive.
31 = LOAD FD SET
FlashDrop parameter values as defined by the FlashDrop file.
FlashDrop is an optional device for fast copying of parameters to unpowered
drives. FlashDrop allows easy customisation of the parameter list, for
example, selected parameters can be hidden. For more information, see
MFDT-01 FlashDrop user’s manual (3AFE68591074 [English]).
0 = USER S1 LOAD
User 1 macro loaded into use. Before loading, check that the saved
parameter settings and the motor model are suitable for the application.
-1 = USER S1 SAVE
Save User 1 macro. Stores the current parameter settings and the motor
model.
-2 = USER S2 LOAD
User 2 macro loaded into use. Before loading, check that the saved
parameter settings and the motor model are suitable for the application.
-3 = USER S2 SAVE
Save User 2 macro. Stores the current parameter settings and the motor
model.
-4 = USER S3 LOAD
User 3 macro loaded into use. Before loading, check that the saved
parameter settings and the motor model are suitable for the application.
-5 = USER S3 SAVE
Save User 3 macro. Stores the current parameter settings and the motor
model.
