Required tools
To install the drive, you need the following tools:
• screwdrivers (as appropriate for the mounting hardware used)
• wire stripper
• tape measure
• drill (if the drive is installed with screws/bolts)
• mounting hardware: screws or bolts (if the drive is installed with screws/bolts). For
the number of screws/bolts, see section With screws on page 25.
Unpacking
The drive (1) is delivered in a package that also contains the following items (frame
size R0 shown in the figure):
• plastic bag (2) including clamping plate, I/O clamping plate, clamps and screws
• mounting template, integrated into the package (3)
• user’s manual (4).
3
1
4
2
