Actual signals and parameters
Parameters in the Long parameter mode
Index
Name/Selection
Description
Def
16 SYSTEM
CONTROLS
Run enable, parameter lock etc.
1601 RUN ENABLE
Selects a source for the external Run enable signal.
0 = NOT SEL
0 = NOT SEL
Allows the drive to start without an external Run enable signal.
1 = DI1
External signal required through digital input DI1. 1 = Run enable. If Run
enable signal is switched off, the drive does not start or coasts to stop if it is
running.
2 = DI2
See selection DI1.
3 = DI3
See selection DI1.
4 = DI4
See selection DI1.
5 = DI5
See selection DI1.
-1 = DI1(INV)
External signal required through inverted digital input DI1. 0 = Run enable.
If Run enable signal is switched on, the drive does not start or coasts to stop
if it is running.
-2 = DI2(INV)
See selection DI1(INV)
-3 = DI3(INV)
See selection DI1(INV)
-4 = DI4(INV)
See selection DI1(INV)
-5 = DI5(INV)
See selection DI1(INV)
1602 PARAMETER LOCK
Selects the state of the parameter lock. The lock prevents parameter
changing from the control panel.
1 = OPEN
0 = LOCKED
Parameter values cannot be changed from the control panel. The lock can be
opened by entering the valid code to parameter 1603 PASS CODE.
The lock does not prevent parameter changes made by macros.
1 = OPEN
The lock is open. Parameter values can be changed.
2 = NOT SAVED
Parameter changes from the control panel are not stored into the permanent
memory. To store changed parameter values, set parameter 1607 PARAM
SAVE value to 1 (SAVE).
1603 PASS CODE
Selects the pass code for the parameter lock (see parameter 1602
PARAMETER LOCK).
0
0…65535
Pass code. Setting 358 opens the lock. The value reverts back to 0
automatically.
1604 FAULT RESET SEL
Selects the source for the fault reset signal. The signal resets the drive after
a fault trip if the cause of the fault no longer exists.
0 = KEYPAD
0 = KEYPAD
Fault reset only from the control panel
1 = DI1
Reset through digital input DI1 (reset on the rising edge of DI1) or from the
control panel
2 = DI2
See selection DI1.
3 = DI3
See selection DI1.
4 = DI4
See selection DI1.
5 = DI5
See selection DI1.
7 = START/STOP
Reset along with the stop signal received through a digital input, or from the
control panel.
-1 = DI1(INV)
Reset through inverted digital input DI1 (reset on the falling edge of DI1) or
from the control panel
-2 = DI2(INV)
See selection DI1(INV).
