97
Actual signals and parameters
Parameters in the Long parameter mode
Index
Name/Selection
Description
Def
-3 = DI3(INV)
See selection DI1(INV).
-4 = DI4(INV)
See selection DI1(INV).
-5 = DI5(INV)
See selection DI1(INV).
1606 LOCAL LOCK
Disables entering the local control mode or selects the source for the local
control mode lock signal. When local lock is active, entering the local control
mode is disabled (LOC/REM key of the panel).
0 = NOT SEL
0 = NOT SEL
Local control is allowed.
1 = DI1
Local control mode lock signal through digital input DI1. Rising edge of digital
input DI1: Local control disabled. Falling edge of digital input DI1: Local
control allowed.
2 = DI2
See selection DI1.
3 = DI3
See selection DI1.
4 = DI4
See selection DI1.
5 = DI5
See selection DI1.
7 = ON
Local control is disabled.
-1 = DI1(INV)
Local lock through inverted digital input DI1. Rising edge of inverted digital
input DI1: Local control allowed. Falling edge of inverted digital input DI1:
Local control disabled.
-2 = DI2(INV)
See selection DI1(INV).
-3 = DI3(INV)
See selection DI1(INV).
-4 = DI4(INV)
See selection DI1(INV).
-5 = DI5(INV)
See selection DI1(INV).
1607 PARAM SAVE
Saves the valid parameter values into the permanent memory.
0 = DONE
0 = DONE
Saving completed
1 = SAVE
Saving in progress
1610 DISPLAY ALARMS
Activates/deactivates alarms OVERCURRENT (code: A2001),
OVERVOLTAGE (code: A2002), UNDERVOLTAGE (code: A2003) and
DEVICE OVERTEMP (code: A2006). For more information, see chapter
Fault tracing on page 127.
0 = NO
0 = NO
Alarms are inactive.
1 = YES
Alarms are active.
1611 PARAMETER VIEW
Selects the parameter view, that is which parameters are shown on the
control panel.
Note: This parameter is visible only when it is activated by the optional
FlashDrop device. FlashDrop allows easy customisation of the parameter list,
for example, selected parameters can be hidden. For more information, see
MFDT-01 FlashDrop users manual (3AFE68591074 [English]).
FlashDrop parameter values are activated by setting parameter 9902
APPLIC MACRO to 31 (LOAD FD SET).
0 = DEFAULT
0 = DEFAULT
Complete long and short parameter lists
1 = FLASHDROP
FlashDrop parameter list. Does not include short parameter list. Parameters
which are hidden by the FlashDrop device are not visible.
