Actual signals and parameters 281
Index Name/
Selection
E-CLIPSE AC500
MODBUS
9902 APPLIC
MACRO
15 = ECLIPSE 21 = AC500
MODBUS
1001 EXT1
COMMANDS
10 = COMM 10 = COMM
1002 EXT2
COMMANDS
10 = COMM 0 = NOT SEL
1003 DIRECTION 1 = FORWARD 1 = FORWARD
1102 EXT1/EXT2
SEL
0 = EXT1 8 = COMM
1103 REF1 SELECT 1 = AI1 8 = COMM
1106 REF2 SELECT 19 = PID1OUT 19 = PID1OUT
1201 CONST
SPEED SEL
0 = NOT SEL 3 = DI3
1304 MINIMUM AI2 20.0% 20.0%
1401 RELAY
OUTPUT 1
7 = STARTED 1 = READY
1601 RUN ENABLE 7 = COMM 7 = COMM
1805 DO SIGNAL 2 = RUN 2 = RUN
2008 MAXIMUM
FREQ
50.0 Hz 50.0 Hz
2201 ACC/DEC 1/2
SEL
0 = NOT SEL 0 = NOT SEL
2202 ACCELER
TIME 1
30.0 s 30.0 s
2203 DECELER
TIME 1
30.0 s 30.0 s
3019 COMM FAULT
TIME
10.0 s 10.0 s
4001 GAIN 2.5 2.5
4002 INTEGRATION
TIME
3.0 s 3.0 s
4101 GAIN 2.5 2.5
4102 INTEGRATION
TIME
3.0 s 3.0 s
8116 AUX MOT
STOP D
3.0 s 3.0 s
8118 AUTOCHNG
INTERV
0.0 = NOT SEL 0.0 = NOT SEL
8123 PFA ENABLE 0 = NOT SEL 0 = NOT SEL
