Parameters 295
Loading A user set is being loaded. 1
Saving A user set is being saved. 2
Faulted Invalid parameter set. 3
User set 1 User set 1 has been loaded. 4
User set 2 User set 2 has been loaded. 5
User set 3 User set 3 has been loaded. 6
User set 4 User set 4 has been loaded. 7
96.11 User set save/load Enables the saving and restoring of up to four custom sets of
parameter settings. See section User parameter sets (page
74).
The set that was in use before powering down the drive is in
use after the next power-up.
Notes:
• Hardware configuration settings such as fieldbus and
encoder configuration parameters (groups 14…16, 51…56,
58 and 92…93, and parameters 50.01 and 50.31), and
forced input/output values (such as 10.03 and 10.04) are
not included in user parameter sets.
• Parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
• If no sets have been saved, attempting to load a set will
create all sets from the currently active parameter settings.
• Switching between sets is only possible with the drive
stopped.
No action
No action Load or save operation complete; normal operation. 0
User set I/O mode Load user parameter set using parameters 96.12 User set I/O
mode in1 and 96.13 User set I/O mode in2.
1
Load set 1 Load user parameter set 1. 2
Load set 2 Load user parameter set 2. 3
Load set 3 Load user parameter set 3. 4
Load set 4 Load user parameter set 4. 5
Save to set 1 Save user parameter set 1. 18
Save to set 2 Save user parameter set 2. 19
Save to set 3 Save user parameter set 3. 20
Save to set 4 Save user parameter set 4. 21
No. Name/Value Description Def/FbEq16
