296 Parameters
96.12 User set I/O mode
in1
When parameter 96.11 User set save/load is set to User set
I/O mode, selects the user parameter set together with
parameter 96.13 User set I/O mode in2 as follows:
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 92). -
96.13 User set I/O mode
in2
See parameter 96.12 User set I/O mode in1. Not selected
96.20 Time sync primary
source
Defines the 1st priority external source for synchronization of
the drive’s time and date.
The date and time can also be directly set into 96.24…96.26
in which case this parameter is ignored.
DDCS
Controller
Internal No external source selected. 0
DDCS Controller External controller. 1
Fieldbus A Fieldbus interface A. 3
Embedded FB Embedded fieldbus interface. 6
Panel link Control panel, or Drive composer PC tool connected to the
control panel.
8
Ethernet tool link Drive composer PC tool through an FENA module.9
96.24 Full days since 1st
Jan 1980
Number of full days passed since beginning of the year 1980.
This parameter, together with 96.25
Time in minutes within 24
h and 96.26 Time in ms within one minute makes it possible to
set the date and time in the drive via the parameter interface
from a fieldbus or application program. This may be
necessary if the fieldbus protocol does not support time
synchronization.
-
1…59999 Days since beginning of 1980. 1 = 1
No. Name/Value Description Def/FbEq16
Status of source
defined by par.
96.12
Status of source
defined by par.
96.13
User parameter
set selected
00Set 1
10Set 2
01Set 3
11Set 4
