Quick start-up guide
23
Parameter setting examples – ACS350
PROFIdrive communication profile with PPO Type 1
The start/stop commands and reference are according to the
PROFIdrive profile. (See the PROFIBUS state machine on page
61.) The reference value ±16384 (4000h) corresponds to
parameter 1105 REF1 MAX in forward and reverse directions.
