Drive configuration
45
Table 2. FPBA-01 configuration parameters – Group B
1 DATA OUT 1
This parameter represents data word 1 received by the drive over
the PROFIBUS network. The content is defined by a decimal
number in the range of 0 to 9999 as follows:
Par.
no.
Parameter name Alternative settings Default
setting
1DATA OUT 1
(master to drive)
0 to 9999
Format: xxyy, where
xx = parameter group and
yy = parameter index.
1 (Control word)
or
11 (Control
word 32-bit)*
2 DATA OUT 2 See DATA OUT 1 above. 0 or 2 (REF1)**
3 DATA OUT 3 See DATA OUT 1 above. 0
4 DATA OUT 4 See DATA OUT 1 above. 0
5 DATA OUT 5 See DATA OUT 1 above. 0
6 DATA OUT 6 See DATA OUT 1 above. 0
7 DATA OUT 7 See DATA OUT 1 above. 0
8 DATA OUT 8 See DATA OUT 1 above. 0
9 DATA OUT 9 See DATA OUT 1 above. 0
10 DATA OUT 10 See DATA OUT 1 above. 0
11 DATA OUT 11*** See DATA OUT 1 above. 0
12 DATA OUT 12*** See DATA OUT 1 above. 0
*Default setting if the Transparent 32 profile is used.
**Fixed setting with an ACS350 drive.
***Supported only with an ACSM1/ACS850 drive.
0 not used
1…99 virtual address area of drive control
101…9999 parameter area of the drive
