Drive configuration
41
Drive configuration
Overview
This chapter gives information on configuring the drive for
communication through the FPBA-01 PROFIBUS DP Adapter
module.
PROFIBUS connection configuration
After the FPBA-01 PROFIBUS DP Adapter module has been
mechanically and electrically installed according to the instructions
in previous chapters, the drive must be prepared for
communication with the module.
The detailed procedure of activating the module for PROFIBUS
DP communication with the drive is dependent on the drive type.
Normally, a parameter must be adjusted to activate the
communication (see the drive documentation).
As communication between the drive and the FPBA-01 is
established, several configuration parameters are copied to the
drive. These parameters – shown below in Tables 1 to 3 – must be
checked first and adjusted where necessary. The alternative
selections for these parameters are discussed in more detail
below the tables.
Note: The new settings take effect only when the module is
powered up the next time or when a ‘Fieldbus Adapter parameter
refresh’ command is given (see the drive documentation).
Data transfer rates supported
The FPBA-01 supports the following PROFIBUS communication
speeds: 9.6 kbit/s, 19.2 kbit/s, 45.45 kbit/s, 93.75 kbit/s, 187.5
kbit/s, 500 kbit/s, 1.5 Mbit/s, 3 Mbit/s, 6 Mbit/s, 12 Mbit/s.
The FPBA-01 automatically detects the communication speed and
telegram type used.
