Mechanical installation
35
Mechanical installation
WARNING! Follow the safety instructions given in this manual and
the drive documentation.
Mounting
The FPBA-01 is to be inserted into its specific position in the drive.
The module is held in place with plastic pins and one screw. The
screw also provides the earthing of the fieldbus cable shield
connected to the module.
On installation of the module, the signal and power connection to
the drive is made through a 20-pin connector. (All drives do not
use all the available signals so the connector on the drive may
have fewer pins.)
Mounting procedure:
• Insert the module carefully into its position on the drive.
• Fasten the screw.
Note: Correct installation of the screw is essential for fulfilling the
EMC requirements and for proper operation of the module.
