FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E 89
Submenu / parameter
Value range
Remark
Submenu Set the time-out limits and alarm behavior for values over or
under the electrode balance.
The electrode balance is calculated as the ratio between the
electrode AC voltages E1/E2. This value is displayed in [%]. If
the electrode voltage E2 is larger than E1, the value is
assigned a minus sign and the ratio E2/E1 is displayed.
Alarm Elec Bal
Min. value
100 ... 300
Lower range limit for alarm.
0.0 %
Max. value
100 ... 300
Upper range limit for alarm.
300.0 %
Message
Off, warning, error
Defines the alarm behavior.
Off Notice: To properly display the electrode voltage, the
electrode zero point must be adjusted. For additional
information, see ‘Submenu Adjustment’ on page 93.
Submenu Set the time-out limits and alarm behavior for values over or
under the magnetic linearity.
Alarm Mag Lin
Min. value 0 ... 100 Lower range limit for alarm.
0.0 %
Max. value 0 ... 100 Upper range limit for alarm.
100.0 %
Message Off, warning, error Defines the alarm behavior.
Off
Notice: If magnetic linearity is being measured (at least every
5 minutes), the most recently acquired flow rate during the
measurement is retained (approx. 2 s).
