436 Parameters
SSMx.04 SSM4 activity and
version
Activates or deactivates the SSM4 function
and shows the version of the SSM4 function.
Disabled
Disabled Deactivates the SSM4 function.
Version 1 Activates version 1 of the SSM4 function.
SSMx.11 SSM1 input Sets the digital input connected to the SSM1
function.
None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
Always on The SSM1 function is always on.
SSMx.12 SSM1 limit negative Sets the negative speed limit for the SSM1
function.
0.0 rpm
-35880.0 …0.0 rpm Speed
SSMx.13 SSM1 limit positive Sets the positive speed limit for the SSM1
function.
0.0 rpm
0.0…35880.0 rpm Speed
SSMx.14 SSM1 output Sets the digital output connected to the
SSM1 function. Active when the motor
speed is within the SSM1 speed limits.
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
SSMx.21 SSM2 input Sets the digital input connected to the SSM2
function.
None
Index Name/Value Description Factory
default
