ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Group objects
104 2CDC509086D0201 | ABA/S 1.2.1
8.2 Inputs and outputs
No. Object Function Name Data type Flags
1…500
Applied from the logic editor
Blank
According to the
definition in the
logic editor
C, R, W, T
This group object is defined via the logic editor.
Unique names can be entered in the logic editor Properties window.
Table 8: Inputs and outputs
8.3 Time synchronization
No.
Object Function
Name
Data type
Flags
501 In operation General 1 bit
DTP 1.001
C, T
For a description, see
Send Group Object "In Operation" (1-bit)
502
Request object
Device Clock
1 bit
DPT 1.017
C, T
This group object queries the date/time from a time master after device start-up.
30 seconds after start-up this group object will send a 1.
503
Date
Device Clock
3 byte
DPT 11.001
C, R, W
This group object receives the date.
504 Time Device Clock 3 byte
DPT 10.001
C, R, W
This group object receives the time.
Only time information is evaluated. Day of the week information is not taken into account.
505
Date/Time
Device Clock
8 byte
DPT 19.001
C, R, W
This group object receives the combined date and time.
Only date and time is evaluated. Other information provided by this datapoint (e.g. year or weekday) is not taken into account.
Table 9: Time synchronization
