7.10.9 1ofN (ONE-HOT)
Description
Logical 1ofN link.
Inputs
No. DPT Abbr. Name Visible Description
1 1 bit I
1
Input Always
2 1 bit I
2
Input Always
3-16 1 bit I
n
Input Parametrizable n = 3...16
Outputs
No. DPT Abbr. Name Visible Description
1 1 bit O Output Always
Note
You can invert 1-bit inputs and outputs by double-clicking on the relevant I/O.
Parameters
Name Value Visible Description
Input Count 2...16 Always
Function
Whenever a telegram is received the output starts a recalculation independently if the value has changed.
The output is (1) if exactly one input is true (1).
I
1
I
2
I
3
O
0
0
0
0
0
0
1
1
0
1
0
1
0
1
1
0
1
0
0
1
1
0
1
0
1
1
0
0
1
1
1
0
