ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Parameters
30 2CDC509086D0201 | ABA/S 1.2.1
7.2 User interface – menu description
7.2.1 File menu
Save
Save can only be used after a cha
nge.
Export
Exports the whole project to an XML file. Linked group addresses are not
exported along with it. If you wish to copy a project with the group addresses, you
can do so using the Copy function in ETS.
Import
All existing data is retained when you import an xml file. The only additional items
imported are worksheets.
Import composite
function block
Imports a user
-defined function block (fbxml file).
After import, the composite function block is shown bottom left in the list of
function elements
in Own function blocks.
Print
Options:
Print All
Print Current Worksheet
The size of the printout matches the scaling on the user interface.
Print Preview
Options:
Full Preview
Previews the current worksheet
The size of the print preview matches the
scaling on the user interface.
Check
Provides an overview of free resources:
Elements (total number of function elements)
Used logic link objects (number of socket I/Os)
Used web objects (number of web I/Os)
Download image size (volume of data downloaded
to the device)
Settings
Main settings for device operation.
