ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Parameters
ABA/S 1.2.1 | 2CDC509086D0201 63
7.10.19 Gate (GATE)
Description
Disables or enables the transmission of values. If the Gate is disabled, the output remains unchanged and
will not trigger a recalculation.
Inputs
No. DPT Abbr. Name Invertible Visible Description
1 Any I Input No Always
2 1 bit I Control Yes Always Disables/enables the output
Outputs
No. DPT Abbr. Name Invertible Visible Description
1 Any O Output No Always
Parameters
Name
Value Visible Description
Control triggers
calculation
yes
no
Always yes: The output sends a value every time Control receives
one.
Function
Control = 1 (true): The output sends every time an input value is received (enabled)
Control = 0 (false): The output does not send (disabled)
Other
If the Control input is not linked, the Gate is enabled for value transmission.
