ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Parameters
70 2CDC509086D0201 | ABA/S 1.2.1
7.10.26 Delay (DELAY)
Description
Received values are forwarded after a defined delay.
Inputs
No. DPT Abbr. Name Visible Description
1 Any I Input Always
2 4 byte signed D Delay Parametrizable
Value in seconds;
according to KNX DPT
13.100
Outputs
No. DPT Abbr. Name Visible Description
1 Any O Output Always
Parameters
Name Value Visible Description
Delay Checkbox Always Enables input D (Delay)
hh:mm:ss Default value:
00:00:00
If the checkbox is
deselected
Parameter and input
according to KNX DPT
13.100.
Range from 00:00:00 to
99:59:59.
Values outside the range
are set to the minimum or
maximum value
respectively.
If the Delay checkbox is selected, the time value fields are not visible.

ABB i-bus KNX ABA/S 1.2.1 Specifications

General

Brand	ABB
Model	i-bus KNX ABA/S 1.2.1
Category	Controller
Language	English
