ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Parameters
ABA/S 1.2.1 | 2CDC509086D0201 57
7.10.16 Minimum/Maximum (MIN/MAX)
Description
Finds the largest or smallest of up to 16 values. The inputs can also be linked with fixed values (constant).
Inputs
No. DPT Abbr. Name Visible Description
1 1 bit F Function Parametrizable
2 Any I
1
Input value Always
3 Any I
2
Input value Always
4-16 Any I
n
Input value Parametrizable n = 3...16
Outputs
No. DPT Abbr. Name Visible Description
1 Any O Output Always
Parameters
Name Value Visible Description
Input Count 2-16 Always
Input parameters
Name Value Visible Description
Min Checkbox Always Enables element input F
Checkbox If the checkbox is deselected
1 = Minimum
0 = Maximum
