7.10.15 Lower or Equal (LOWER/EQUAL)
Description
Compares two input values. Both inputs can also be linked with fixed values (constant).
Inputs
No. DPT Abbr. Name Visible Description
1 Numeric value I
1
Input Always
2 Same as Input 1 I
2
Input Parametrizable
Outputs
No. DPT Abbr. Name Visible Description
1 1 bit O Output Always
Parameters
Name Value Visible Description
In 2 Checkbox Always
Numeric value If the checkbox is deselected Data type as for Input 1
Function
The output is 1 if I
1
is less than or equal to I
2
.
The output is 0 if I
1
is greater than I
2
.
Whenever a telegram is received the output starts a recalculation independently if the value has changed.
