Parameters
40 2CDC509086D0201 | ABA/S 1.2.1
Element display
• Element name
• First group address
• Data widths (1 bit, 2 bits, 4 bits, 1 byte, 2 bytes, 4 bytes, date, time, date/time, color)
Note
The first group address is the one that sends a value. The group addresses are displayed in the same
layout as in ETS (e.g. 2-level or 3-level).
Icons:
• Read group address = True (1): icon
Datapoint type
Select the datapoint type required for displaying the value on the KNX accordingly.
All assigned group addresses are listed in Data Types in the Properties window. They cannot be changed
(read-only).
