ABB i-bus KNX ABA/S 1.2.1 User Manual

ABB i-bus
®
KNX
Parameters
78 2CDC509086D0201 | ABA/S 1.2.1
Parameters
The Time section defines the time of day when the output is 1, otherwise the output is 0.
The Recurrence section is for setting the days on which the element is active. On these days the output
value is 1. On all other days it is 0.
Note
Recurrence Every ... day(s), Every ...week(s) on, ...month(s), Every ...year(s) starts on the date set in the
Duration section.
The Duration section is for setting the dates between which the element is active.
All the parameters can also be set via inputs. Selecting the corresponding As input checkbox activates the
inputs.
Time section parameters
Fig. 13: Time section parameters
Parameter Name Value Description
Start Time of day in minutes Default = 00:00:00 Sets the start time
End Time of day in minutes Default = 00:00:00 Sets the end time
Whole time 1 bit Default = false (0) Sets a whole day
Active 1 bit Default = false (0)
Activates/deactivates the
element
