Parameters
86 2CDC509086D0201 | ABA/S 1.2.1
Inputs
No. DPT Abbr. Name Visible Description
1 See above I Input Always
2 See above F Factor Parametrizable
3 See above O Offset Parametrizable
Outputs
No. DPT Abbr. Name Visible Description
1 See above O Output Always
Parameters
Name Value Visible Description
Factor Single Float Always Enables Factor input
Offset Single Float Always Enables Offset input
Calculation
• The output is calculated as input * Factor + Offset.
• If the output result is greater than the data type concerned:
the maximum for the data type is applied to the output.
• If the output result is less than the data type concerned:
the minimum for the data type is applied to the output.
The N-CONV element can be used to divide a 2-byte unsigned value into an upper and lower byte.
• The lower value is calculated using Factor = 1.
• The unsigned upper 2-byte value is calculated using Factor = 0.00390625 (= 1/256).
• The unsigned upper 4-byte value is calculated using Factor = 0.0000152587890625 (= 1/65536).
• The conversion of a 1-byte unsigned value from a value range 0...255 into 0...100 is calculated using
Factor = 0.00390625.
Other
Unlinked inputs are treated as if they did not exist.
