ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 143
Interfaces
Template
Options:
KNX to WebUI
KNX to BACnet
KNX to ASM output socket
WebUI to KNX
WebUI to KNX with update
BACnet to KNX
BACnet to KNX with update
ASM input socket to KNX
Freely configurable
You can select predefined templates for the most frequent situations. Then the following interface
parameters within the ASM are set automatically. These interface parameters are visible, but cannot then
be changed.
Alternatively, you can select all interface parameters as required by selecting the Freely configurable
option. In this way it is possible, for example, to set up bidirectional data exchange between several
interfaces.
You will find the descriptions of the individual templates in the following sections:
KNX to WebUI
KNX to BACnet
KNX to ASM output socket
WebUI to KNX
WebUI to KNX with update
BACnet to KNX
BACnet to KNX with update
ASM input socket to KNX
Freely configurable
