Draining oil, axis-1 gearbox
Use this procedure to drain oil in gearbox axis 1.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
WARNING
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety informa-
tion in the section Safety risks during work with
gearbox lubricants (oil or grease) on page 36.
2
Shown in Location of oil plugs on
page 122.
Remove oil plug, filling, in order to drain oil quicker!3
Shown in Location of oil plugs on
page 122.
Remove oil plug, draining, and drain gearbox using
a hose with a nipple and an oil collecting vessel.
4
Vessel capacity is specified in
Required equipment on page 123.
Note
Draining is time-consuming.
Elapsed time depends on the
temperature of the oil.
Tightening torque: 25 Nm.Refit oil plugs.5
Filling oil, axis-1 gearbox
Use this procedure to fill gearbox axis 1 with oil.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
WARNING
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety information
in the section Safety risks during work with gearbox
lubricants (oil or grease) on page 36.
2
Continues on next page
124 Product manual - IRB 460
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
3 Maintenance
3.4.2 Changing oil, axis-1 gearbox
Continued
